6809495A75-O October 14, 2005 19
Level 1 and 2 Service Manual Disassembly
Removing and Replacing the SIM
1. Remove the battery cover and battery as described in the procedures.
2. Unlock the SIM holder by sliding it away from the SIM.
3. Lift up the SIM and remove it from the phone (see Figure 6).
4. To replace, slide the SIM into the SIM holder with the notched corner located
as shown.
5. Lock the SIM holder by sliding it toward the SIM.
6. Reassemble the battery and battery cover as described in the procedures.
050778o
Figure 6. Removing and Replacing the SIM
SIM
SIM Holder
unlock
