6809495A75-O October 14, 2005 33
Level 1 and 2 Service Manual Disassembly
7. Carefully thread the display flex connector through the opening on the chassis
assembly.
8. Lower the display module fully onto the chassis assembly and gently press it
into place.
9. Reassemble the transceiver PC board, antenna, SIM, battery, and battery
cover as described in the procedures.
