When pairing mode is active the LED Status Indicator will blink, alternating between amber and
green.
c. Tap Continue
5. Wait for re-pairing to successfully complete.
6. Choose one of the following actions:
● If re-pairing is successful, tap Continue
● If re-pairing is unsuccessful, tap Try Again and repeat the re-pairing process.
3.6.3
Installing the Camera
Prerequisites: Any external power options are installed.
The Camera Mounting Bracket is installed.
The camera is paired to the Mobile Companion application.
The internal camera batteries are fully charged.
Obtain:
● Long Range Antenna and Angle Adapter
● Mobile Phone Pouch
Procedure:
1. Select from one of the following options:
If... Then...
If the Internal Battery On-
ly power option is being
used,
go to step Step 3.
If the camera is using an
external power option,
connect the elbow power connector to the camera:
a. Align the elbow connector with the lower port on the back of the
camera by rotating until the connector drops in.
NOTE: The elbow power connector is keyed so that it
can only connect when rotated into the correct position.
b. Tighten down the locking sleeve.
2. Insert the ball on the back of the camera into the ball socket on the mounting bracket.
Tighten the ball joint enough to keep the camera in place, but still allow it to pivot.
3. Remove the protective film from the camera lens.
4. Attach the Mobile Phone Pouch.
a. Insert the mobile phone into the Mobile Phone Pouch.
b. Hook the pouch on the lower Metal Band Strap.
c. Ensure that the phone and pouch are secure.
