1 - 14 MC3000 User Guide
Figure 1-13 Strap/Door Removal and Replacement (MC3090G)
Turning Off the Radios
On Device with Windows CE 5.0 (OEM Version 01.15 or lower)
WLAN Radio
To turn off the WLAN radio:
1. Tap Start > Settings > Control Panel > Power icon > PwrDevices tab.
2. In the text box, scroll down until WLP1: displays.
3. Select WLP1:. WLP1: displays in the text box at the top of the window.
4. In the drop-down list box, select D4.
5. Tap Set.
To turn on the radio:
1. Tap Start > Settings > Control Panel > Power icon > PwrDevices tab.
2. In the text box, scroll down until WLP1: displays.
0.5 in.
(12.7 mm)
Strap/Door
Assembly
Latches
Button
Loop
NOTE To determine the operating system OEM version, see Configurations on page xii.
