Motorola MC55 Integrator Guide

7 - 10 MC55 Integrator Guide
Four Slot Spare Battery Charger
Cables
MC55 battery is not
recharging.
MC55 was removed from
the cradle too soon.
Replace the MC55 in the cradle. The 2400 mAh battery fully
charges in approximately four hours and the 3600 mAh
battery charges in approximately six hours.
Battery is faulty. Replace the battery.
MC55 is not placed
correctly in the cradle.
Remove the MC55 from the cradle, and re-insert correctly. If
the battery still does not charge, contact customer support.
The MC55 battery charging LED slowly blinks amber when
the MC55 is correctly inserted and charging.
Ambient temperature of
the cradle is too warm.
Move to an area where the ambient temperature is between
0
o
C and 35
o
C.
Table 7-5 Troubleshooting the Vehicle Cradle
Symptom Possible Cause Action
Table 7-6 Troubleshooting the Four Slot Spare Battery Charger
Symptom Possible Cause Action
Battery not charging. Battery was removed
from the charger or
charger was unplugged
from AC power too soon.
Re-insert the battery in the charger or re-connect the charger’s
power supply. The 2400 mAh battery fully charges in
approximately four hours and the 3600 mAh battery charges in
approximately six hours.
Battery is faulty. Verify that other batteries charge properly. If so, replace the
faulty battery.
Battery contacts not
connected to charger.
Verify that the battery is seated in the battery well correctly with
the contacts facing down.
Table 7-7 Troubleshooting the Cables
Symptom Possible Cause Action
MC55 battery is
not charging.
MC55 was
disconnected from AC
power too soon.
Connect the power cable correctly. Confirm main battery is charging
under Start > Settings > System > Power. The 2400 mAh battery
fully charges in approximately four hours and the 3600 mAh battery
charges in approximately six hours.
Battery is faulty. Verify that other batteries charge properly. If so, replace the faulty
battery.
The MC55 is not fully
attached to power.
Detach and re-attach the power cable to the MC55, ensuring it is
firmly connected.

Motorola MC55 Specifications

General

Barcode Scanner	1D laser scanner or 2D imager
Operating System	Windows Mobile 6.1
Display	3.5 in. QVGA color display
Wireless Connectivity	Wi-Fi 802.11 a/b/g, Bluetooth 2.0
GPS	Optional
Expansion Slots	SD slot
Camera	Optional
Keyboard	QWERTY
