Motorola MC55 Integrator Guide

ActiveSync 3 - 3
Setting Up an ActiveSync Connection on the Host Computer
To start ActiveSync:
1. Select Start > Programs > Microsoft ActiveSync on the host computer. The ActiveSync Window displays.
Figure 3-2 ActiveSync Window
2. In the ActiveSync window, select File > Connection Settings. The Connection Settings window appears.
Figure 3-3 Connection Settings Window
3. Select Allow USB connections checkbox.
4. Select the Show status icon in Taskbar check box.
5. Select OK to save any changes made.
NOTE Assign each mobile computer a unique device name. Do not try to synchronize more than one mobile
computer to the same name.

Motorola MC55 Specifications

General

Barcode Scanner	1D laser scanner or 2D imager
Operating System	Windows Mobile 6.1
Display	3.5 in. QVGA color display
Wireless Connectivity	Wi-Fi 802.11 a/b/g, Bluetooth 2.0
GPS	Optional
Expansion Slots	SD slot
Camera	Optional
Keyboard	QWERTY
