Motorola MC55 Integrator Guide

Accessories 2 - 25
Assembly
1. Insert the vehicle holder’s cradle plate to the holes on the back of the cradle.
2. Push the cradle down until both parts are engaged.
Windshield Installation
1. Fix the suction cup mount to the selected area with the suction lever facing up.
Figure 2-25 Windshield Installation
2. Flip the lever down to create a vacuum between the suction cup and the mounting surface.
3. Make sure that the suction bond is strong enough before proceeding to the next step.
4. Slide the MC55 into the cradle.
Cradle Plate
Cradle
Suction Cup Mount

Motorola MC55 Specifications

General

Barcode Scanner	1D laser scanner or 2D imager
Operating System	Windows Mobile 6.1
Display	3.5 in. QVGA color display
Wireless Connectivity	Wi-Fi 802.11 a/b/g, Bluetooth 2.0
GPS	Optional
Expansion Slots	SD slot
Camera	Optional
Keyboard	QWERTY
