Getting Started 1 - 3
7. Close SIM card holder door and slide down to lock into place.
8. Close rubber access door.
Installing the SIM Card
GSM phone service requires a Subscriber Identification Module (SIM) card, or smart card. Obtain the card from the
your service provider. The card can contain the following information:
•
Mobile phone service provider account details.
•
Information regarding service access and preferences.
•
Contact information, which can be moved to Contacts on the MC55.
•
Any additional services to which you have subscribed.
To install the SIM card:
1. Lift rubber access door.
2. Slide the SIM card holder up to unlock.
3. Lift the SIM card holder door.
Figure 1-3
Lifting the SIM Cover
4. Insert the SIM card, as shown in Figure 1-4 ensuring that the card slides into the holding tabs on each side of
the door.
NOTE MC5574 configuration only.
NOTE For more information about SIM cards, refer to the service provider's documentation.
