Motorola MC55 Integrator Guide

Accessories 2 - 7
Figure 2-5 Daisychaining Four Slot Ethernet Cradles
Ethernet Cradle Drivers
The MC55 includes Ethernet cradle drivers that initiate automatically when you place the MC55 in a properly
connected Four Slot Ethernet cradle. After inserting the MC55, configure the Ethernet connection:
1. Tap Start > Settings > Connections tab >WiFi icon. The Configure Network Adapters window appears.
Figure 2-6 Configure Network Adapters Window
2. In the My network card connects to: drop-down list, select the appropriate connection.
3. In the Tap an adapter to modify settings: list, select USB/Ethernet Series Adapter.
Ethernet Port 1
Ethernet Port 2
Link LED
Speed LED

Motorola MC55 Specifications

General

Barcode Scanner	1D laser scanner or 2D imager
Operating System	Windows Mobile 6.1
Display	3.5 in. QVGA color display
Wireless Connectivity	Wi-Fi 802.11 a/b/g, Bluetooth 2.0
GPS	Optional
Expansion Slots	SD slot
Camera	Optional
Keyboard	QWERTY
