Motorola MOTORAZR V3 - Exploded View Parts List

6809511A13-O April 20, 2007 47
Level 1 and 2 Service Manual Troubleshooting
Exploded View Parts List
To order parts please use the following Link:
https://wissc.motorola.com/wissc_root/main/BrowserOK.html
(Password is Required)
For information on ordering parts please contact EMEA at + 49 461 803 2690.
Table 5. Exploded View Parts List
Item
Part
Number
Description Item Part Number Description
1 0588721Z01 Grommet, Upper Camera
26 0590070N01 RF grommet
2 2615255H01 Camera socket cover 27 7588489Z45 Conductive pad, display bezel
3 4289441Y01 Grounding contact, Flip inner
28 6188659Z08 Lens, camera glass
4 9471516E08
066X6 VGA Camera Imager, Altus OVT,
Razr
29 3288422Z21 Gasket Camera Glass
5 0588722Z01 Grommet bottom, camera 30 6188659Z05 Lens, CLI
6 1588807Z03
Housing, Flip Inner, Painted/Finished
Razor
31 3890014N01 Button, carrier
7 3890012N01 Button, Volume control
32 1589127Y01 Housing, end cap/hinge
8 6190016N11 Lens, main display 33 490214N01 Grounding clip for hinge cap
9 0387726M09 Screws, X4
34 5590242N02 Hinge cam silent, 5.8mm x 5.1mm
10 3890022N01 Bumper, knuckle X2
35 3588010Y04 Mesh, speaker port
11 1571482D08 Housing, end cap shaft -- 0387726M09 Screw
12 3288422Z18 Dust resistant gasket
37 1587510Y01 Housing sleeve, hinge spacer
13 3288422Z17 Water resistant Mid
38 7287518Y01 CLI display
14 8489976N05 Keypad FLEX PCB 39 3890013N01 Button, smart
15
1590043N17
1590043N20
Front housing assembly silver
Front housing assembly black
40 3888182Y03 Keypad assembly, English
16 3890023N02 Bumper nose
41 0188045Z01 Display external bezel assembly
17 1487942Y07 Battery Insulator -- 3987941Y01 Contact, grounding flip
18 0187349Y01 Battery package
43 0188045Z12 Personality Flex assembly
19
0164096T01
0164096T02
Battery door silver
Battery door black
44 3288422Z19 Dust resistant gasket down
20 3988406Y01 Contact, grounding bootstrap 45 7271542E01 Assembly, LCD module display 176x220
21 3887388Y01 Button plug bladder #2
46 0387347Y01 Screws, PT custom panhead X4
22 1590051N03 Antenna assembly
47 3887389Y01 Button plug bladder #1
23
0164095T01
0164095T02
Rear housing assembly silver
Rear housing assembly black
48 6087603L01 RTC battery
24 0387473K08 Screws Mag form 5 IP Black XCVR,X2
49 CHLF4604AA Assembly, PCB XCVR
25
1587371Y01
1587371Y02
Housing front antenna cover painted silver
Housing front antenna cover painted black
50
1587373Y01
1587373Y02
Housing, front antenna cosmetic cap
painted silver
Housing, front antenna cosmetic cap
painted black
