MW800 User’s Guide 13
Bottom-Side Components
The Hard Disk Compartment is located at the bottom of the CPU box. The Hard
Disk Compartment contains the removable hard disk drive.
Figure 4. Bottom View – Hard Disk Drive
Top View
Figure 5. Top View
Ventilation
Openings The openings ensures proper air circulation to prevent
overheating. Never cover or block these openings.
Ventilation
Openings
