20
Section 3: Specifications
Specifications
Size
• CPU:
Width: 7.75” (19.7 cm); Depth: 9.45” (24.0 cm); Height: 2.74” (6.95 cm)
• 12.1” Display:
Width: 12.2” (31 cm); Depth: 10.6” (26.9 cm); Height: 2.2” (5.6 cm)
• 8.4” Display:
Width: 9.1” (23.1 cm); Depth: 7.1” (18.1 cm); Height: 1.69” (4.3 cm)
• Keyboard:
Width: 7.75” (19.7 cm); Depth: 9.45” (24.0 cm); Height: 2.74”
Weight
• CPU: 7.7 pounds (3.5 kg)
• 12.1” Display: 8.4 pounds (3.8 kg)
• 8.4” Display: 3.3 pounds (1.5 kg)
• Keyboard: 2.2 pounds (1.0 kg)
Power source
• Vehicle battery, negative ground.
• Voltage Input Variation13.8 VDC ± 20% with no loss of functionality.
• Power loss compensation during engine cranking in standard 13.8 VDC
battery system.
• Current consumption at 13.8 VDC:
! Maximal 5A
! Typical 3.5A (CPU - 1.5A, Display – 2A)
! Standby 0.4 A
! Power off 0.05 A.
• Capability to support 9 VDC vehicle battery.
• Vehicle ignition switch sensing.
• Electrical Transients meet ISO7637-1 standard.
• Car battery voltage (1A maximum) and 5 VDC (1A maximum) power outputs
to peripherals from AUX port. Voltage level at 12VDC output is equal to car
battery voltage input.
Environment
• Storage temperature: -40° to 158° F (-40° to +70° C)
• Operating temperature: -22° to 158° F (-30° to +70° C)
• Humidity: 90 to 95% Relative humidity at 50° C for 8 hours
Refer to Appendix E for detailed Environmental specifications.
