Level III Service Manual Tools and Test Equipment
Tools and Test Equipment
The following tables list the tools and test equipment used on V70 telephones.
Use either the listed items or equivalents.
Table 2. General Test Equipment and Tools
Motorola
Part Number
1
Description Application
See Table 7 Charger Used to charge battery and to power device
0180386A82
Antistatic Mat Kit (includes 66-80387A95 antistatic
mat, 66-80334B36 ground cord, and 42-80385A59
wrist band)
Provides protection from damage to device caused
by electrostatic discharge (ESD)
8102430Z04 GSM / DCS / PCS Test SIM Used to enable manual test mode
6680388B67 Disassembly tool, plastic with flat and pointed
ends (manual opening tool)
Used during assembly/disassembly of device
6680388B01 Tweezers, plastic Used during assembly/disassembly
RSX4043-A Torque Driver Used to remove and replace screws
—
Torque Driver Bit T-6 Plus, Apex 440-6IP Torx Plus
or equivalent
Used with torque driver
HP34401A
2
Digital Multimeter Used to measure battery voltage
1. To order in North America, contact Motorola Aftermarket and Accessories Division (AAD) by phone at (800) 422-4210 or
FAX (800) 622-6210; Internationally, AAD can be reached by calling (847) 538-8023 or faxing (847) 576-3023.
2. Not available from Motorola. To order, contact Hewlett Packard at (800) 452-4844.
1 and 2
6881039B25
C23
