6881039B25 January 08, 2002 19
Level III Service Manual Disassembly
Removing and Replacing the Subscriber Identity Module (SIM)
1. Remove the battery cover and battery as described in the procedures.
2. Remove the SIM by sliding it in the direction of the arrow as shown in Figure 6.
3. To replace, carefully slide the SIM into its socket. Be sure the SIM is correctly
positioned to contact the terminals in the phone.
4. Replace the battery and battery cover as described in the procedures.
011099-o
Figure 6. Removing the SIM
SIM
