8 Settings via the MICT
Rev. 08/2018 65
Manual/Auto
The status display indicates the operation mode selected:
– green: The operation mode is set.
– yellow: A command is carried out in the operation mode selected. In automatic operation
mode, the status display will only turn yellow if position 1 or 2 is approached.
– red: An error occurred in the operation mode selected.
Stepper Motor
The status display indicates the condition of the stepper motor:
– green: The stepper motor is ready.
– yellow: The stepper motor is active.
– red: An error occurred.
Warning/Error
A red status display indicates that an error or a warning message occurred. The display will go
out if the error or warning is acknowledged via the MICT (Device -> Error Acknowledge). Refer to
the section Runtime Data – Message Log on page 66.
Opening
– Target
The value is assigned to the stepper motor driver in automatic mode by the master control
or, in manual mode, by the MICT or the Open/Close buttons on the device.
– Actual
The displayed value corresponds to the opening percentage of the throttle or the gas supply
of the gas mixer.
