Motortech VariStep3 - Varifuel2 to Varistep3 Stepper Motor Driver

12 Annex
Rev. 08/2018 85
Connector Stepper Motor + Encoder
Labeling Pin VariStep/ VariStep3
Encoder GND 1
Encoder 5V/Power 2
Encoder A 3
Encoder B 4
Encoder I 5
Encoder Shield 6
Stepper Motor Phase B2 7
Stepper Motor Phase B1 8
Stepper Motor Shield 9
Stepper Motor Phase A2 10
Stepper Motor Phase A1 11
12.1.2 VariFuel2 to VariStep3 Stepper Motor Driver
Assignment of the wire colors
Take the assignment of the wire colors of the wiring harness from the wiring
diagram enclosed with the wiring harness.
