Connector Digital Outputs -> Connector Binary Outputs
Labeling VariStep Pin Labeling VariStep3
ERRORout + 11 Error +
ERRORout - 12 Error -
CLOSEout + 13 Close +
CLOSEout - 14 Close -
OPENout + 15 Open +
OPENout - 16 Open -
POS1out + 17 Pos. 1 +
POS1out - 18 Pos. 1 -
POS2out + 19 Pos. 2 +
POS2out - 20 Pos. 2 -
OFFLINEout + 21 Offline +
OFFLINEout - 22 Offline -
Connector Analog Inputs/Outputs
Labeling VariStep Pin VariStep Pin VariStep3 Labeling VariStep3
Uin + 23 23 Position U in +
Uin GND 24 24 Position GND
Iin + 25 25 Position I in +
Iin - 26 26 Position I in -
– – 27 Shield
Uout + 28 29 Position U out +
Uout/Iout GND 29 30 Position GND
Iout + 30 31 Position I out +
Connector Power
Labeling VariStep Pin VariStep Pin VariStep3 Labeling VariStep3
Power IN + 1 1 L +
Power IN - (Earth) 2 2 L -
Power IN - (Earth) 3 3 Earth
