CLOCKWORKS FOR MAC OS 9
89
Frame lock/freewheel status
This line in the status display tells you if your MOTU
interface is frame-locked or if it is currently freewheeling.
The terms you will see here are:
■ Frame-locked
■ Jam
Frame-locked
This status indicator means that your MOTU interface is
successfully locked to an external time base and that it is
also successfully generating or converting SMPTE time
code.
Jam (MIDI Timepiece AV only)
This option only applies to a MOTU MIDI Timepiece AV
interface. If you have one, refer to your MIDI
Timepiece AV manual.
Timebase measure
This option only applies to a MOTU MIDI Timepiece AV
interface. If you have one, refer to your MIDI
Timepiece AV manual.
Actual Frame Rate
This option only applies to a MOTU MIDI Timepiece AV
interface. If you have one, refer to your MIDI
Timepiece AV manual.
Video Out Phase Lock
This option only applies to a MOTU MIDI Timepiece AV
interface. If you have one, refer to your MIDI
Timepiece AV manual.
Output phase lock
When this status indicator is illuminated, it means that
time code generated by your MOTU interface (MTC and
LTC) is in sync with the current time base.
Input frame phase lock
When this status indicator is illuminated, it means that
your MOTU interface has successfully achieved lockup
with incoming LTC/MTC full frame messages.
Input quarter frame phase lock
When this status indicator is illuminated, it means that
your MOTU interface has successfully achieved lockup
with incoming LTC/MTC quarter frame messages.
