Rev 7 21 (EN)
Now place your robot into the working area, next to the charging station.
A green flashing LED on the base station indicates wrong
installation of the boundary wire.
Press the main power switch to “ON”.
Now open the display cover, press the power soft button for three seconds. After a short
boot of the operating system, enter the PIN code “1234”, confirm with “OK”, press the key
Marked HOME and then close the
LCD cover
. Now your mower should follow the wire in
an anti-clockwise direction and dock into the charging position. The mower will start
to fully charge. If robot misses
to
dock, you might have to adjust the charging station
sideways until the robot docks without any
pr
oblem.
Stop moving at any time
If you want to stop the robotic mower at any time during cutting, please press the red
STOP button. Once the STOP button is pressed, the lawnmower will stop and wait for your
