Rev 7 22 (EN)
further commands. The lawn mower will not start to work until you have entered your PIN
and closed the LCD cover.
5.6 SECURE THE CHARGING BASE
Once the robotic mower can work normally and the charging station has been found
suitable location, use a hammer and knock down the fixing nails fully home to secure
the base. Remember: The
wire must not be kinked or damaged.
The protective bar from the scope of delivery prevents the robot from unintentionally
breaking out of the working area in case of incorrect initial installation. Attach it under the
station as shown in the sketch.
As last step, please remove the boundary wire from the base
station again, cut off all superfluous length and re-connect it
straight to the connectors without any loops or knots.
