LED
Color
State
Description
10M/100M/
1000M
Copper
Bottom LED
Green
On
TP port’s 10/100Mbps link is active.
Blinking
Data is being transmitted at
10/100Mbps.
Off
TP port’s 10/100Mbps link is
inactive.
10M/100M
Copper Top
LED
Green
On
TP port’s 100Mbps link is active.
Blinking
Data is being transmitted at
100Mbps.
Off
TP port’s 100Mbps link is inactive.
10M/100M
Copper
Bottom LED
Green
On
TP port’s 10Mbps link is active.
Blinking
Data is being transmitted at 10Mbps.
Off
TP port’s 10Mbps link is inactive.
100M/1000M
(SFP port)
Green
On
When the port is active and links on
1000Mbps.
Blinking
When the port’s data is being
transmitted at 1000Mbps.
Off
When the port is inactive or link
down.
Amber
On
When the port is active and links on
100Mbps.
Blinking
When the port’s data is being
transmitted at 100Mbps.
Off
When the port is inactive or link
down.
Auto MDI/MDI-X Connection
The Auto MDI/MDI-X function allows users to connect the EDS’s
10/100/1000BaseT(X) ports to any kind of Ethernet device, without
paying attention to the type of Ethernet cable being used for the
connection. This means that you can use either a straight-through cable
or cross-over cable to connect the EDS to Ethernet devices.
Triple Speed Functionality and Switching
The EDS’s 10/100/1000 Mbps RJ45 switched port auto negotiates with
the connected device for the fastest data transmission rate supported
by both devices. The EDS is a plug-and-play device, so software
configuration is not required at installation or during maintenance.
The half/full duplex mode for the RJ45 switched ports is user dependent
and changes (by auto-negotiation) to full or half duplex, depending on
which transmission speed is supported by the attached device.

Moxa Technologies EDS-2010-ML Series Specifications

General

Brand	Moxa Technologies
Model	EDS-2010-ML Series
Category	Switch
Language	English
