Overview
The EDS-2010/2018-ML series of industrial Ethernet switches are
equipped with 8/16-ports 10/100M copper ports and 2
10/100/1000BaseT(X) or 100/1000BaseSFP combo ports. The switches
are ideal for applications that require high-bandwidth data convergence
and long-distance uplinks.
The EDS-2010/2018-ML provides 12/24/48 VDC redundant power
inputs, and the switches are available with a standard operating
temperature range from -10 to 60°C, or with a wide operating
temperature range from -40 to 75°C. The switches are rugged enough
to operate reliably in harsh industrial environments.
To provide greater versatility for use with applications from different
industries, the EDS-2010/2018-ML also allow users to enable or disable
broadcast storm protection, Quality of Service (QoS) function, and port
break alarm function with DIP switches on the outer panel.
The EDS-2010/2018-ML switches can be easily installed with DIN-Rail
mounting as well as distribution boxes. The DIN-rail mounting
capability and IP30 metal housing with LED indicators make the plug-
and-play EDS-2010/2018-ML switches reliable and easy to use.
Throughout this Quick Installation Guide, we use EDS as an
abbreviation for Moxa EtherDevice Switch:
EDS = Moxa EtherDevice Switch
This device complies with part 15 of FCC Rules. Operation is
subject
to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Package Checklist
Your EDS is shipped with the following items. If any of these items are
missing or damaged, please contact your customer service
representative for assistance.
• Moxa EtherDevice™ Switch
• Quick installation guide (printed)
• Warranty card
• Protective caps for unused ports
