Specifications
Technology
Standards IEEE 802.3 for 10BaseT,
IEEE 802.3u for 100BaseT(X) and 100Base FX,
IEEE 802.3ab for 1000BaseT,
IEEE 802.3z for 1000BaseSX/LX/LHX/ZX
IEEE 802.1p for Class of Service
Flow Control
IEEE 802.3x flow control, back pressure flow
control
Interface
RJ45 Ports
10/100BaseT(X) and 10/100/1000BaseT(X) auto
negotiation speed
Fiber Ports
100/1000Base-X SFP slot
LED Indicators PWR1, PWR2, Fault, 10/100M, 10/100M/1000M,
100M, 1000M
DIP Switch
Port break alarm, QoS, BSP
Alarm Contact
One relay output with current carrying capacity
of 1A @ 24 VDC
Switch Properties
MAC Table Size
8 K
Packet Buffer Size
4 Mbits
Processing Type
Store and Forward
Power
Input Voltage
12/24/48 VDC redundant dual inputs
Input Current
EDS-2010-ML: 0.606 A (max.)
EDS-2018-ML: 0.617 A (max.)
Relay output: 24 VDC, 1 A, Resistance
Connection
Removable 6-contact terminal block 28-14 AWG,
1.71 in-lbs
All wires must be able to withstand at least 85°C
Overload Current
Protection
Present
Reverse Polarity
Protection
Present
Mechanical
Casing
IP30 protection, metal case
Dimensions (W x H
x D)
EDS-2010-ML:
36 x 135 x 95 mm (1.41 x 5.31 x 3.74 in)
EDS-2018-ML:
58 x 135 x 95 mm (2.28 x 5.31 x 3.74 in)
Weight
EDS-2010-ML: 498 g (1.10 lb)
EDS-2018-ML: 683 g (1.51 lb)
Installation
DIN-rail, Wall Mounting (optional kit)
Environmental Limits
Note: Only for indoor use.
Operating
Temperature
-10 to 60°C (32 to 140°F)
-40 to 75°C (-40 to 167°F) for -T models
Storage
Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
