Moxa Technologies NPort 5210A User Manual

NPort 5000 Series User Manual
168
Console
Web console
Telnet console
C
C
Ping
C
Save/Restart
C
The part of the LCM operation that still requires some explanation is how to edit the configurable options. In
fact, you will only encounter two types of configurable options.
The first type involves entering numbers, such as IP addresses, Netmasks, etc. In this case, you change the
number one digit at a time. The up cursor (△) is used to decrease the highlighted digit, the down cursor
(▽) is used to increase the highlighted digit, and the SEL button is used to move to the next digit. When the
last digit has been changed, pressing SEL simply enters the number into the NPort’s memory. The second
type of configurable option is when there are only a small number of options from which to choose
(although only one option will be visible at a time). Consider the PARITY attribute under PORT SETTING as
an example. Follow the tree graph to arrive at the following PARITY screen. The first option, NONE, is
displayed, with a down arrow all the way to the right. This is an indication that there are other options from
which to choose.
P
a
r
i
t
Y
N
o
n
e
↓
Press the down cursor button once to see Odd as the second option.
P
a
r
i
t
Y
↑
O
d
d
↓
Press the down cursor button again to see Even as the third option.
P
a
r
i
t
Y
↑
E
v
e
n
↓
Press the down cursor button again to see Space as the fourth option.
P
a
r
i
t
Y
↑
M
a
r
k
↓
Press the down cursor button yet again to see the last option, Space.
P
a
r
i
t
Y
↑
S
p
a
c
e
To choose the desired option, press the SEL button when the option is showing on the screen.

Moxa Technologies NPort 5210A Specifications

General

Baud rate	230.4 Kbit/s
Data bits	5, 6, 7, 8
Stop bits	1, 1.5, 2
Certification	CE, FCC
RS-232 signals	CTS, DCD, DSR, DTR, GND, RTS, Rx, Tx
Flow control support	Yes
Serial interface type	RS-232
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Mean time between failures (MTBF)	134850 h
Product color	Black, Blue
Housing material	Metal
Input voltage	12 - 48 V
Power consumption	325 mA
Storage temperature (T-T)	-40 - 75 °C
Maximum operating altitude	2000 m
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	ICMP, IPv4, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, SNTP

Weight and Dimensions

Weight	340 g
Dimensions (WxDxH)	90 x 100.4 x 22 mm
