Moxa Technologies NPort 5210A User Manual

NPort 5000 Series User Manual
27
If the firmware is not up to the version below, you many need to key in the password manually.
NPort 5100A Series Firmware v1.5
NPort 5200A Series Firmware v1.5
NPort 5150AI Series Firmware v1.4
NPort 5250AI Series Firmware v1.4
NPort 5450AI Series Firmware v1.4
NPort 5600 Series Firmware v3.9
NPort 5600 DT Series Firmware v2.6
NPort 5600 DTL Series Firmware v1.5
NPort IA5150A Series Firmware v1.4
NPort IA5450A Series Firmware v1.6
NOTE
The configuration encrypting function is not available in the NPort 5100, NPort 5200, and NPort IA5000
Series.
Refer to the table below for the firmware versions that support the encrypted configuration files in the Web
Console.
Model Name
Firmware version supporting encrypted configuration files.
NPort 5100A Series
Firmware v1.3 and up
NPort 5200A Series
Firmware v1.3 and up
NPort 5x50AI-M12 Series
Firmware v1.2 and up
NPort IA5150A, NPort IA5250A
Firmware v1.3 and up
NPort IA5450A
Firmware v1.4 and up

Moxa Technologies NPort 5210A Specifications

General

Baud rate	230.4 Kbit/s
Data bits	5, 6, 7, 8
Stop bits	1, 1.5, 2
Certification	CE, FCC
RS-232 signals	CTS, DCD, DSR, DTR, GND, RTS, Rx, Tx
Flow control support	Yes
Serial interface type	RS-232
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Mean time between failures (MTBF)	134850 h
Product color	Black, Blue
Housing material	Metal
Input voltage	12 - 48 V
Power consumption	325 mA
Storage temperature (T-T)	-40 - 75 °C
Maximum operating altitude	2000 m
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	ICMP, IPv4, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, SNTP

Weight and Dimensions

Weight	340 g
Dimensions (WxDxH)	90 x 100.4 x 22 mm
