NPort 6000 Series Software Installation/Configuration
For example: If you want to map port 15 only for NPort 6000 (A), the configuration will be as follows:
MAC Address of NPort The MAC address of NPort (A) for identification 00:90:18:18:f1:36
1st Mapping Port Index Index or port 15 15
Total Number of Ports Only port 15 will be mapped, and the total
number of ports should be 1
1
For example: If you want to map ports 3 to 15 for NPort 6000 (A), the configuration will be as follows:
MAC Address of NPort The MAC address of NPort (A) for identification 00:90:18:18:f1:36
1st Mapping Port Index Index the port 3 3
Total Number of Ports From port 3 to port 15 will be mapped, and the
total number of ports should be 13
13
4. Ports that have been activated will appear in black.
5. For Reverse Real COM mode, users should assign the TCP port number for the Remote Host/Server. Click
the Configuration tab to modify the port number.
This is the TCP port number assignment for the remote host/server. It is the port number that the serial port
of the NPort 6000 uses to establish the connections with Remote Host/Server. To avoid conflicts with
well-known TCP ports, the default is set to 60950.
