MSC Pro-Source - Key Modification and Cutting; Key Decoding and Code Entry

ENGLISH
16 Pro-Source Man. cod. B411107FG MSC
MODIFY AND CUT
7Modify and cut
7. 1 .0 D ec od e
This function makes it possible to decode the key using the se-
lected key system.
How to proceed:
• From the key search sub-menu, select “ ”.
• Insert the original key in the jaws and lock it in place.
• Then follow the instructions on screen until the end of the de-
coding process.
Note: If the key has a shoulder stop, insert it in the clamp with
the special magnetic catch as shown in the console.
Warning: Important!
It is not possible to cut and decode painted keys or key
made of non-conductive material.
7.2 .0 C od e
This function makes it possible to search for a specific code con-
tained in the data base and obtain the relevant coding.
How to proceed:
• From the key search sub-menu, select “ ”.
• Input the blind code.
•Then press “
►” to go to the following screen, the key “CUT-
TING” one (for additional information, please refer to para-
graph7.5.0 on page17).
Warning: Important!
It is not possible to cut and decode painted keys or key
made of non-conductive material.
7. 3. 0 D i re ct
This function makes it possible to insert the bitting code for the
key directly.
How to proceed:
• From the key search sub-menu, select “ ”.
• Input a value for each cut that shall correspond to the bitting
code.
•Then press “
►” to go to the following screen, the key “CUT-
TING” one (for additional information, please refer to para-
graph7.5.0 on page17).
Warning: Important!
It is not possible to cut and decode painted keys or key
made of non-conductive material.
