MSC Pro-Source Man. cod. B411107FG 5
MACHINE DESCRIPTION
2.2.1 Parts- Machine
1. Tracer holder
2. Cutter
3. Jaw
4. Knob to lock jaw
5. Tracer height adjustment knob
6. Chip tray
7. Protective eye guard
8. Stop button
9. RJ25 console connector
10. External power supply connector
11. External power supply
12. Console
2.3.0 Optional clamps
The following optional clamps can also be used with the Pro-
Source machine:
• H type clamp for Tibbe systems (6 spaces)
• V type clamp for new Volkswagen
®
laser keys (4 sides)
4
5
6
2
1
3
7
8
910
11
12
