1. Supports only SDRAM DIMM.
2. To operate properly, at least one 168-pin DIMM module must be installed.
3. This mainboard supports Table Free memory, so memory can be installed
on DIMM 1 or DIMM 2 in any order.
4. Supports 3.3 volt DIMM.
5. The single-/double-sided memory modules supported by each DIMM slot
are shown below:
Memory Population Rules
SDRAM DIMM Module Combination
Socket Memory Module Total Memory
DIMM 1
(Bank0 & Bank1)
S/D 32MB ~ 512MB
DIMM 2
(Bank2 & Bank3)
S/D 32MB ~ 512MB
Maximum System Memory Supported 32MB ~ 1GB
S (Single Side) D (Double Side)
