Crankshaft, piston and connecting rod
103
Engine torque values chart
NOTE: * - apply a small amount of releasable thread locking compound such as Loctite® 242 (blue).
Fastener in lbs Nm
Blower housing studs 80 - 106 9 - 12
Breather cover 53 - 71 6 - 8
Carburetor drain bolt 49 - 80 5.5 - 9
Carburetor mounting nuts 62 - 80 7 - 9
Connecting rod cap bolts
177 - 212*
20 - 24
Drain plug 106 - 124 12 - 14
Flywheel nut 74 - 85 ft-lbs 100 - 115
Head bolt 41 - 44 ft lbs step 55 - 60 step
Module 80-106 9 - 12
Exhaust manifold at head 266 - 310 30 - 35
Exhaust manifold at muffler 177 - 212 20 - 24
Rocker jam nut 80-106 9 - 12
Rocker stud 195 - 221 22 - 25
Spark plug 177 - 212 20 - 24
Starter (recoil) 80-106 9 - 12
Starter (electric) 195 - 221 22 - 25
Sump bolts 195 - 221 22 - 25
Valve cover 62 - 80 7 - 9
