Mechanical locks (Ultima SL)
Mechanical hook locks
The mechanical hook locks attach the container to the hook arm’s auxiliary frame and thus
also to the frame of the truck. The locks are equipped with proximity switches that allow
the use of the hook arm when the locks are open.
The mechanical hook locks must be opened manually on both sides before using the device.
Function When the hook locks are closed, When the hook locks are open,
the LED turns on the LED turns o󰀨
LEDs
2GCC
Display
and LEDs
2GRC
