Construction
Ultima S / SL hooklift equipment contains frames joined to each other which enable
loading, unloading and tipping of a container. The rear frame hinged to the rear end of the
sub-frame, which is fastened to the truck chassis, enables tipping of the container. The
middle frame hinged to the rear frame together with the hook arm sliding inside it, enable
container loading and unloading.
Container standards, as well as the dimensions dened by them, a󰀨ect the hooklift
construction. The height and shape of the container gripping bar have an e󰀨ect on the
dimensions of the gripping hook; the most common gripping heights are 57.1 in (1450 mm)
and 61.8 in (1570 mm). The tunnel height between the container runs denes the height of
the hooklift equipment body supports, and the rear rollers, and the distance between the
runs, the width of the rear rollers.
The most common tunnel heights are 3.9 in (100 mm), 4.9 in (125 mm) and 5.9 in (150
mm), and the most common width is 41.9 in (1065 mm).
The shape and the position of the hydraulic and mechanical body locks in the hooklift
equipment are dened according to the container standards. The used container lengths
also have an e󰀨ect to the position.
