109
Ultima S / SL Flex & Pro
3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
>>>
!
>>>
1 2 1 2
1 1
1 2 1 2
Stabilizer
• Stabilizer or a support roller is available as additional equipment. It improves the
stability of vehicle during loading and unloading.
• In new constructions, the circumstances impairing the stability of vehicle are smaller
own weight and larger loading capacity.
1 Stabilizers are used with the help of switches located in the cabin, which switches
control the additional valves assembled to the directional control valve assembly.
NOTE! Stabilizers should never be used during tipping.
Function Engage bogie blocking Release bogie blocking
LED comes on LED goes out
LEDs
2GCC
Display
and LEDs
2GRC
LEDs
2GMR
Button
