Ultima S / SL Flex & Pro
3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
Service Manual
!
LUBRICATION
Lubricate all the lubrication points at max 3 month intervals. A more recommended lubrication
interval would be 1 month.
NOTE! The hooklift equipment contains plastic surface slide bearings.
Use LITHIUM based general lubrication grease (EP2)
or biodegradable lubricant NLGI 2.
Molybden based lubricant shortens the service life of the
bearings.
If the hooklift is equipped with a central lubrication system, this will need to be checked
according to the manufacturer’s instructions.
Optional sensors:
219 Crane body on / Front lock left / Body on, Ø18 or Ø30 NO or NC
220 Front lock right / Bogie blocking on, Ø18 or Ø30 NO or NC
305 Hook arm in front, Ø18 NO
313 Tilt indicator, middle frame
314 Angle switch rear frame
320 Hook arm back, Ø18 NO
321 Pull limiter (DE) or Locking beam, Ø18 NO
322 URB in, Ø18 NO
323 URB out or Bogie blocking on, Ø18 NO
TS-SF Tilt indicator, sub-frame
TS-MF Tilt indicator, middle frame
RS-HA Wire sensor, hook frame
PT-MC Pressure transducer, main cylinder
