MULTILIFT Ultima S Flex - Page 35

35
Ultima S / SL Flex & Pro
3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
16. Move the hook arm forward
- move the CONTROL LEVER to left and forward (2GCC)
- press the HOOK ARM FORWARD button (2GMR and 2GRC).
Continue the movement until the container is in its transport position.
Movement will close also the mechanical tipping lock.
17. Close the hydraulic body locks
- press the BODY LOCKS CLOSED button.
Signal light LOCKS NOT CLOSED must go out.
Also close the mechanical or hydraulic front locks (optional).
Move the
control
lever to left
forward
Two LEDs
are on
Button
Button
Second
LED
goes out
