Multitech MultiConnect Dragonfly MTQ-MNG6-B02 - Page 10

HARDWARE AND SPECIFICATIONS
10 MultiConnect
®
Dragonfly
TM
MTQ-MNG6-B02 Device Guide
Pin Definitions
Pin Signal Name Logic Level Voltage
1
Max
Voltage
In/Out Description
1 NC
2 NC
3 NC
4 NC
5 GND GND GND Ground Connection
6 USB-DATA+ See USB 2.0 Spec for
levels
3.6V I/O USB Data+ connection to cellular
module
7 USB-DATA- USB Data- connection to cellular
module
8 VCC-IN 2.75V - 5.25V 5.25V Power Input Main Power
9 RADIO_RXD 0 - 3V O Cellular Radio UART Data Output
10 RADIO_DCD 0 - 3V O Cellular Radio UART Data Carrier
Detect
11 RADIO_RI 0 - 3V O Cellular Radio UART Ring
indicator
12 RADIO_CTS 0 - 3V O Cellular Radio UART Clear to Send
(flow control)
13 GND GND GND Ground Connection
14 NC
15 NC
16 NC
17 NC
18 NC
19 NC
20 NC
21 NC
22 NC
23 NC
24 NC
