ANTENNAS
14 MultiConnect
®
Dragonfly
TM
MTQ-MNG6-B02 Device Guide
Chapter 4 – Antennas
Requirements for Cellular Antennas with regard to FCC/IC
Compliance
This device has been designed to operate with the antennas listed below and having a maximum antenna gain of
6.18 dBi for the 700 MHz band, 6.00 dBi for 1700 MHz band, and 9.01 dBi for the 1900 MHz frequency band.
Antennas not included in this list or that have a gain greater than specified are strictly prohibited for use with this
device. The required antenna impedance is 50 ohms.
External Antenna Option
Cellular Antenna
Cellular devices were approved with the following antenna:
Manufacturer: Wieson
Model Number: ARY118-0167-001-00
MultiTech ordering information:
Model Quantity
ANLTE4V2-1HRA 1
ANLTE4V2-2HRA 2
ANLTE4V2-10HRA 10
ANLTE4V2-50HRA 50
Cellular Antenna Specifications
Category Description
Frequency Range 617-960 MHz
1447-2690 MHz
3300-3800 MHz
Impedance 50 Ohms
VSWR 619-960 MHz: 2.5:1
1447-2690 MHz: 2:1
3300-3800 MHz: 2:1
Peak Gain 619-960 MHz: 1.89 dBi
1447-2690 MHz: 3.95 dBi
3300-3800 MHz: 1.56 dBi
Radiation Omni-directional
