Electrical Characteristics
Operating Conditions
Parameter Minimum Volts Maximum Volts
Supply Range - Vcc 2.75 5.25
Absolute Maximum Rating
Parameter Minimum Volts Maximum Volts
Voltage at any signal pin -0.3 5.5
DC Electrical Characteristics
Parameter Conditions Minimum Volts Maximum Volts
Digital signal input low level CMOS port
I
IO
=+8 mA
-0.3 0.9
Digital signal input high level CMOS port
I
IO
=+8 mA
2.1 5.5
Output low level voltage for an I/O pin CMOS port
I
IO
=+8 mA
- 0.4
Output high level voltage for an I/O pin V
DD
-0.4 -
Output low level voltage for an I/O pin TTL port
I
IO
=+8 mA
- 0.4
Output high level voltage for an I/O pin 2.4 -
Output low level voltage for an I/O pin I
IO
=+20 mA - 1.3
(1)
Output high level voltage for an I/O pin V
DD
-1.3
(1)
-
Output low level voltage for an I/O pin I
IO
=+6 mA - 0.4
(1)
Output high level voltage for an I/O pin V
DD
-0.4
(1)
-
Output low level voltage for an I/O pin I
IO
=+4 mA - 0.4
(2)
Output high level voltage for an I/O pin V
DD
-0.4
(2)
-
RESET (low active) input low CMOS port
I
IO
=+8 mA
- 0.99
RESET (low active) input high CMOS port
I
IO
=+8 mA
2.31 -
RESET (low active) input high CMOS port
I
IO
=+8 mA
5.00 -
(1) Guaranteed by characterization results, not tested in production.
(2) Guaranteed by design, not tested in production.
