Multitech MultiConnect Dragonfly MTQ-MNG6-B02 - 40-Pin Connector

HARDWARE AND SPECIFICATIONS
MultiConnect
®
Dragonfly
TM
MTQ-MNG6-B02 Device Guide 11
Pin Signal Name Logic Level Voltage
1
Max
Voltage
In/Out Description
25 NC
26 NC
27 NC C
28 GND GND GND Ground Connection
29 RADIO_RTS 0 - 3V I Cellular Radio UART Request to
Send (flow control)
30 RADIO_DSR 0 - 3V O Cellular Radio UART Data Set
Ready
31 RADIO_DTR 0 - 3V I Cellular Radio UART Data
Terminal Ready
32 RADIO_TXD 0 - 3V I Cellular Radio UART Serial data
input from DTE
33 VCC-IN 2.75 - 5.25V Power Input Main Power
34 LINK_STATUS 3V O Cellular radio link status LED.
Open drain outputs with 47K pull
up to 3V.
35 RESET 0 - VCC input (VCC-IN) I Radio reset. Input has an internal
pull-up resistor. Drive with an
open drain output. Active low.
36 GND GND GND Ground Connection
37 GND
38 NC
39 NC
40 NC
40-Pin Connector
Manufacturer: Hirose Electric Co LTD
Description: .5MM 40 PN B>B RECEPTACLE
Model Number: DF17(4.0)-40DP-0.5V(57)
Use with:
Manufacturer: Hirose Electric Co LTD
Description: .5mm 40 pin B.B header PLUG
Model Number: DF17(2.0)-40DP-0.5V(57)
