Chapter 1 – Product Overview
MultiModem rCell User Guide 13
Specifications
MTCBA-E1-EN2
General
Standards EDGE: E-GPRS Class 12
GPRS: Multislot Class 12
Frequency Bands Quad-band: 850/900/1800/1900 MHz
Speed
Packet Data* EDGE: E-GPRS up to 240 Kbps, coding scheme MCS1-9, mobile station Class B, LLC layer, 4
time slots
GPRS: Full PBCCH support, coding scheme 1-4, mobile station Class B
Circuit Swithed Data Up to 14.4 Kbps, non-transparent
Physical Description
Dimensions 2.93 in x 7.0 in x 1.24 in
7.44 cm x 17.78 cm x 3.15 cm
Weight (Device Only) 0.75 lbs
0.340 Kg
Connectors
Antenna Connector 50 ohm SMA (female connector)
SIM Holder Standard 1.8 and 3V SIM receptacle
LAN Connector RJ-45, 10/100 BaseT
RS232 Connector DE9
Power Connector 2.5mm miniature (screw-on)
Environment
Operating Temperature** -31° to 167° F
-35° to 75° C
Storage Temperature -40° to 185° F
-40° to 85° C
Humidity Relative humidity 20% to 90% noncondensing
Power Requirements
Operating Voltage 9V to 32V DC
SMS
SMS Text and PDU
Point-to-Point
Cell broadcast
Certifications and Compliance
EMC Compliance FCC Part 15
EN55022 Class B
EN55024
Radio Compliance FCC Part 22, 24
RSS132, 133
EN301 489-1
EN489-3 (GPS models only)
EN301 489-7
EN301 511
AS/ACIF S042.1, S042.3
Safety Certifications UL/cUL 60950-1 2nd Ed
IEC60950-1 2nd Ed am.1
Network Certifications PTCRB
AT&T
