Chapter 1 – Product Overview
14 MultiModem rCell User Guide
GPS
Accuracy Position 2.5m CEP, Velocity 0.1 m/sec
Open Sky TTFF Hot start 1 second
Cold start 29 seconds
Reacquistion <1s
Sensitivity Tracking -165 dBm
Protocol NMEA-0183, V3.01, GGA, GLL, GSA, GSV, RMC, VTG
MTCBA-C1-EN2
General
Standards CDMA2000 1xRTT
Frequency Bands Dual band 800/1900 MHz
Speed
Packet Data* Up to 153.6 Kbps forward and reverse
Circuit Switched Data IS-95A, IS-95B up to 14.4 Kbps forward and reverse
Physical Description
Dimensions 2.93 in x 7.0 in x 1.24 in
7.44 cm x 17.78 cm x 3.15 cm
Weight 0.75 lbs
0.340 Kg
Connectors
Antenna Connector 50 ohm SMA (female connector)
LAN Connector RJ-45, 10/100 BaseT
RS232 Connector DE9
Power Connector 2.5 mm miniature (screw-on)
Environment
Operating Temperature** -40° to 185° F
-40° to 85° C
Storage Temperature -40° to 185° F
-40° to 85° C
Humidity Relative humidity 20% to 90% noncondensing
Power Requirements
Operating Voltage 9V to 32V DC
Certifications and Compliance
EMC Compliance FCC Part 15
Radio Compliance FCC Part 22, 24
Safety Compliance UL/cUL 60950-1 2nd Ed
IEC60950-1 2nd Ed am.1
GPS
Accuracy Position 2.5m CEP, Velocity 0.1 m/sec
Open Sky TTFF Hot start 1 second
Cold start 29 seconds
Reacquistion <1s
Sensitivity Tracking -165 dBm
Protocol NMEA-0183, V3.01, GGA, GLL, GSA, GSV, RMC, VTG
