Chapter 1 – Product Overview
16 MultiModem rCell User Guide
GPS
Accuracy Position 2.5m CEP, Velocity 0.1 m/sec
Open Sky TTFF Hot start 1 second
Cold start 29 seconds
Reacquistion <1s
Sensitivity Tracking -165 dBm
Protocol NMEA-0183, V3.01, GGA, GLL, GSA, GSV, RMC, VTG
* UL Listed @ 40° C, limited by power supply. UL Certification does not apply or extend to an ambient above 40° C
and has not been evaluated by UL for ambient greater than 40° C.
** UL has evaluated this device for use in ordinary locations only. Installation in a vehicle or other outdoor
locations has not been evaluated by UL. UL Certification does not apply or extend to use in vehicles or outdoor
applications or in ambient above 40° C.
MTCBA-H5-EN2
General
Standards HSPA+
Frequency Bands Penta band 850/900/1700/1900/2100 MHz
Speed
Packet Data* HSDPA data service of up to 21.0 Mbps
HSUPA data service of up to 5.76 Mbps
Physical Description
Dimensions 2.93 in x 7.0 in x 1.24 in
7.44 cm x 17.78 cm x 3.15 cm
Weight 0.75 lbs
0.340 Kg
Connectors
Antenna Connector 50 ohm SMA (female connector)
SIM Holder Standard 1.8 and 3V SIM receptacle
LAN Connector RJ-45, 10/100 BaseT
RS232 Connector DE9
Power Connector 2.5 mm miniature (screw-on)
Environment
Operating Temperature** -22°to 167° F
-30° to 75° C
Storage Temperature -40° to 185° F
-40° to 85° C
Humidity Relative humidity 20% to 90% noncondensing
Power Requirements
Operating Voltage 9V to 32V DC
SMS
SMS Text and PDU
Point-to-Point
Cell broadcast
