Chapter 3 – Using the Web Management Software
MultiModem rCell User Guide 79
Serial Port, Client Settings Parameters
The TCP/UDP client feature enables the router to act as a proxy TCP/UDP client to the serial terminal connected to
the DE9, RS232 port on the router thus facilitating the serial terminal to access any TCP/UDP server on the
LAN/WAN. Once the session, serial terminal to TCP/UDP server, is opened successfully, it allows two-way traffic
between the serial device and the remote server.
Initial connection setup for the TCP/UDP client is as follows:
TCP/UDP – Client Configuration Group
Configures TCP/UDP Client through which the serial terminal connected to the RS-232 connector, DE9 on the back
of the unit communicates with the remote TCP/UDP server on the LAN/WAN.
Status: Sets the client status to either Enable or Disable. The default is Disable.
Client Type: Sets the client to either TCP or UDP. The default is TCP.
Primary Server: Enter the Primary Server IP address or Hostname. The default is blank.
Port: If a Primary Server IP address or hostname is enabled, enter the port number of the server.
Secondary Server: Enter the Secondary Server IP address or Hostname. The default is blank.
Port: If a Secondary Server IP address or hostname is enabled, enter the port number of the server.
Connection start By: Sets the trigger (Carriage Return (CR), DTR Assert, or Always on) in the serial port by which
the connection starts. The default is Carriage Return (CR).
Connection Terminate By: Sets the connection terminate sequence as follows:
Router hardware
TCP/UDP
Client
Serial
Device
DE9
Connector
LAN / WAN
TCP/UDP
Server
HyperTerminal /
Minicom
