TECHNICAL SPECIFICATIONS
6
Technical Specifications
Table 1: Display Specification
Table 2: Touch Sensing Hardware
Table 3: Touch Surface
Table 4: Interfaces
Display Technology TFT LCD
Display Size 55" 16:9 Wide
Native Resolution Full HD 1920 x 1080
Display Colors 16.7 million
Display Active Area 1209 x 680 mm
Pixel Pitch 0.63 x 0.63 mm
Pixel Response Time 8ms grey to grey
Brightness 250 cd/m2
Contrast Ratio 4000:1 typical
Picture Frame Rate 60 Hz
Backlight White LED Matrix Array
Viewing Angle 178
Touch technology Computer Vision Through Screen
Tracking Speed Up to 200 fps
IR Source & cameras Integrated Backlight Emitter Camera
modules
IR Wavelength 850 nm
Display Safety Glass Tempered 4 mm Optiwhite Glass
covering whole front surface
Video Input DVI-D, DisplayPort
