Description
Technical specifications
28 11.06.2014
Dimensions
Weight approx. 68 kg
Fig. 12: Dimensions
Installation conditions and ambient conditions
Ambient temperature +2 °C to +40 °C
Storage temperature -25 °C to +80 °C
Relative air humidity during op-
eration or storage of the ma-
chine, max.
90 % non-condensing
Inclination of the machine during
transport, max.
15 °
Requirements for the location of
the machine
• Level surface.
• Sufficient load bearing capac-
ity.
• Free of damage.
Minimum distance on all sides of
the machine
100 mm
Minimum room size for machines
with gas flushing option*
40 m
2
*For safety reasons, a minimum room size is mandatory to prevent
high concentrations of gas.
