Maintenance
Change the air de-oiling element
74 11.06.2014
¾ Attach a sealing ring to the new air de-oiling element.
¾ Insert a new air de-oiling element with sealing ring.
– The arrow on the air de-oiling element points downwards.
¾ Place the screw plug, together with the spring, onto the air de-
oiling element pipe and tighten it. To do so, turn the screw plug
clockwise.
¾ Close housing, see Section 7.5 "OPEN AND CLOSE THE HOUSING".
7.8 Change chamber lid gasket
¾ Open the chamber lid as far as the limit stop and have a second
person hold it.
