Maintenance
Open and close the housing
11.06.2014 67
¾ Open the housing completely (slightly more than 90 °). Close the
chamber lid and hold it closed when opening the housing.
– The whole control terminal is lying flat on the underlayer.
– The base plate of the machine is raised at the pivot point of the
housing by several centimetres.
7.5.2 Close housing
¾ Close the housing. Ensure that there are no cables between the
housing and the base plate.
¾ Tighten the two screws at the rear of the machine. Turn these
screws clockwise.
– The housing is closed and tight.
