1.3 Warning labels and symbols
Warning label Risk lev el
Consequences of disregard
DANGER
Immediate acute risk Death, grievous bodily harm
WARNING
Potential acute risk Death, grievous bodily harm
CAUTION
Potential hazardous situation Minor bodily harm
CAUTION
Potential hazardous situation Material damage
Tab. 3 Warning lab els and consequences of disregarding them
Symbol
Meaning
Safety w arning sign
Take note of all information highlighted by the safety warning sign
and follow the respective instructions to avoid injury or death.
Safety instruction
1. , 2. , ...
Step-by-step safety instructions

Precondition
→
Cross reference
Information, hint
Tab. 4 Symbols and th eir meaning
1.4 Technical terms
Term Meaning
Sealing medium Medium for locking or qu enching of shaft seals
Auxiliary operating systems
Systems for operating the pum p
Tab. 5 Technical term s and their meaning
