Operation
User manual 59719_hdb_en_12 60 / 65
7.4.2 Pin-Based Bitmapping
Input Process Data
Byte 0 Inputs X0 ... X7
Bit Contact
0 Pin4_X0
1 Pin4_X1
2 Pin4_X2
3 Pin4_X3
4 Pin4_X4
5 Pin4_X5
6 Pin4_X6
7 Pin4_X7
Byte 1 Inputs X0 ... X7
Bit Contact
0 Pin2_X0
1 Pin2_X1
2 Pin2_X2
3 Pin2_X3
4 Pin2_X4
5 Pin2_X5
6 Pin2_X6
7 Pin2_X7
Byte 2 Diagnostic
Bit Description
0 Error/Warning at power supply (too low or high)
1 Error/Warning because of temperature rating
(threshold can be defined inside object)
2 Error/Warning at Input/Output (short-circuit or
overload)
3 DIA at channel X
0 = channel 1
...
15 = channel 16
4 DIA at channel X
0 = channel 1
...
15 = channel 16
5 DIA at channel X
0 = channel 1
...
15 = channel 16
6 DIA at channel X
0 = channel 1
...
15 = channel 16
7 Global status
0 = no diagnostic
1 = fault detected
Byte 3 Module Identification
Bit Description
0 ... 7 User defined module identification bits, e. g. for
tool change applications;
0 = not used
1 ... 255 = ID value is read out from object
