Murr Elektronik MVP12 Series - Page 61

Operation
User manual 59719_hdb_en_12 61 / 65
Output Process Data
Byte 0 Outputs X0 ... X3
Bit Contact
0 Pin4_X0
1 Pin2_X0
2 Pin4_X1
3 Pin2_X1
4 Pin4_X2
5 Pin2_X2
6 Pin4_X3
7 Pin2_X3
Byte 1 Outputs X4 ... X7
Bit Contact
0 Pin4_X4
1 Pin2_X4
2 Pin4_X5
3 Pin2_X5
4 Pin4_X6
5 Pin2_X6
6 Pin4_X7
7 Pin2_X7
